LS 5.3 mount angle for stand
Thread Starter
Teching In
Joined: Mar 2012
Posts: 42
Likes: 7
From: East Alabama
LS 5.3 mount angle for stand Looking at the block with my calibrated Mk I Eyeball, it looks like the motor mount location is 45 degrees relative to the ground. Is this a proper assumption? I am building a castered stand for my block to roll around on while it’s in the queue to be built. Anyone have drawing of this angle?
TECH Fanatic
Joined: Jan 2022
Posts: 1,034
Likes: 468
From: Seattle
TECH Senior Member
Joined: Jun 2016
Posts: 22,303
Likes: 3,619
From: Central Cal.
Being that the cylinder banks are splayed 90 degrees, and half of that is 45 degrees, and being that the mount pads are smack against these 45 degree angled cylinder banks, your powers of observation have served you well.
TECH Fanatic
Joined: Jan 2022
Posts: 1,034
Likes: 468
From: Seattle
Thread Starter
Teching In
Joined: Mar 2012
Posts: 42
Likes: 7
From: East Alabama
Ha! I knew it! My Mark I Calibrated Eyeball hasn't failed me yet! Thanks!
