LS2 Alternator Rear Bracket Interchangeability? The LS2 GTO shares the same accesory offset as the LS1 F-body. Posts like this one list the F-Body alternator brackets for use with the GTO LS2, seemingly because the F-Body brackets are less expensive.
The LS2 GTO rear alternator bracket (92059707) appears to be much longer than the F-Body rear bracket (12556915). Are the rear brackets interchangeable if using the stock GTO alternator?
My drivers side motor mount can't slide fully forward due to interference with the GTO rear alternator bracket.
TIA.
Tipsy
Stock LS2 GTO Rear Alternator Bracket (92059707)
Stock F-Body Rear Alternator Bracket (12556915)
The LS2 GTO rear alternator bracket (92059707) appears to be much longer than the F-Body rear bracket (12556915). Are the rear brackets interchangeable if using the stock GTO alternator?
My drivers side motor mount can't slide fully forward due to interference with the GTO rear alternator bracket.
TIA.
Tipsy
Stock LS2 GTO Rear Alternator Bracket (92059707)
Stock F-Body Rear Alternator Bracket (12556915)
I'm not sure dimension wise but the f-body bracket is better suited to the slider style engine mounts. I'm looking to fab up something simple for my gto ls2 as I'm looking at the same issue if I run a Dingo slider. I'll work off the top bolt hole like the f-body.
My E36 Jags That Run kit also uses a slider mount. The stock GTO rear alternator bracket interferes with the mount just a bit. Next time I'm in FL, I should be swinging the engine in for its first test fit. If the rear bracket proves to be an issue, I'll look for an alternative or consider eliminating it altogether.
I just found a picture I took before removing the stock accessories. Compared to the picture above, it looks like the F-Body rear bracket bolts to the hole with the green arrow? Assuming the GTO alternator is dimensionally the same as the F-Body alternator (I don't know if they are) it would appear that using the F-Body rear bracket would eliminate interference with a slider motor mount.
Tipsy
Last edited by TipsyMcStagger; May 20, 2016 at 10:58 PM.
On The Tree
Joined: Jul 2014
Posts: 128
Likes: 0
Yes that's what my set -up looks like. The only difference is the alternator housing where the rear bracket bolt attaches. See how your GTO alternator has a solid round extension where the F-body has the square, 2 piece look to it? My only concern is the length there, too short you can run an aluminum spacer, too long and chop city time.
Trending Topics
Yes that's what my set -up looks like. The only difference is the alternator housing where the rear bracket bolt attaches. See how your GTO alternator has a solid round extension where the F-body has the square, 2 piece look to it? My only concern is the length there, too short you can run an aluminum spacer, too long and chop city time.
Tipsy
Last edited by TipsyMcStagger; Jul 7, 2015 at 01:02 PM.
LS1 Tech Stories
The Best V8 Stories One Small Block at Time
6 Common C5 Corvette Failures and What's Involved In Repairing Them
Pouria Savadkouei
Retro Modern Bandit Pontiac Trans AM Comes With Burt Reynolds' Autograph
Verdad Gallardo
Top 10 Greatest Cadillac V Series Performance Models Ever, Ranked
Pouria Savadkouei
Top 10 Most Powerful Chevy Trucks Ever Made!
Hennessey's New Supercharged Silverado ZR2 Has 700 HP
Verdad Gallardo
Coachbuilt N2A Anteros Is an LS2-Powered C6 Corvette In Italian Clothes
Verdad Gallardo
Awesome K5 Blazer Restomod Comes With C7 Corvette Power
Verdad Gallardo
10 Camaros You Should Never Buy
10 LS Engine Myths That Refuse to Die
Verdad Gallardo
I just ordered one earlier today. I'll post when I get it in hand. For $20 it's worth it even if it doesn't work as I'll be able to reverse engineer it. I do have a vertical mill which some might consider cheating, lol.
The f-body bracket won't work. I ordered one for $20 and it is slightly different. I'll fab up a bracket out of aluminum. May make several and possibly sell the extras on here if there's interest.
