Twin sizing for built 6.0L I have a 370ci iron block that I originally built for NA but impulse led me to place a deposit on the HS twin kit.
Stock crank, forged H-beam rods, wiseco +4cc forged pistons. ~ 11.2:1 CR
Rings are gapped .026" top / .028" bottom
236/246 110 .612/.612 LSX cam
98 Camaro with RXT, T56, 35 spline 9" w/3.70 gears, 28" tire.
I know its not ideal but I would like to leave the setup alone for now. My short term goals are to hit 600-650whp at 8-10lbs until I am more confident in my ability to drive with more. Maybe after I'll build a new bottom end to lower the CR. I'd really like to have the turbos light off by 2500rpm, if not sooner. I'm worried that if I go too small though, I'll choke on the top end because of the CR and big cam.
The VSR turbos that I have been looking at are cast 61/62 T4 .82ar, or cast 67/65 T4 .96ar. Are either of these a good match? I know it's not much of a budget, but I'm trying to stay under $800 for the pair.
Stock crank, forged H-beam rods, wiseco +4cc forged pistons. ~ 11.2:1 CR
Rings are gapped .026" top / .028" bottom
236/246 110 .612/.612 LSX cam
98 Camaro with RXT, T56, 35 spline 9" w/3.70 gears, 28" tire.
I know its not ideal but I would like to leave the setup alone for now. My short term goals are to hit 600-650whp at 8-10lbs until I am more confident in my ability to drive with more. Maybe after I'll build a new bottom end to lower the CR. I'd really like to have the turbos light off by 2500rpm, if not sooner. I'm worried that if I go too small though, I'll choke on the top end because of the CR and big cam.
The VSR turbos that I have been looking at are cast 61/62 T4 .82ar, or cast 67/65 T4 .96ar. Are either of these a good match? I know it's not much of a budget, but I'm trying to stay under $800 for the pair.
Last edited by bj241205; Dec 11, 2019 at 09:48 AM.
9 Second Club
Joined: Nov 2003
Posts: 13,616
Likes: 185
From: Norn Iron
Thread Starter
Teching In
Joined: Jan 2017
Posts: 26
Likes: 3
I decided on twins for quicker spool. I was already removing ABS, AC & PS, so space wasn't a concern.
Trending Topics
9 Second Club
Joined: Nov 2003
Posts: 13,616
Likes: 185
From: Norn Iron
LS1 Tech Stories
The Best V8 Stories One Small Block at Time
6 Common C5 Corvette Failures and What's Involved In Repairing Them
Pouria Savadkouei
Retro Modern Bandit Pontiac Trans AM Comes With Burt Reynolds' Autograph
Verdad Gallardo
Top 10 Greatest Cadillac V Series Performance Models Ever, Ranked
Pouria Savadkouei
Top 10 Most Powerful Chevy Trucks Ever Made!
Hennessey's New Supercharged Silverado ZR2 Has 700 HP
Verdad Gallardo
Coachbuilt N2A Anteros Is an LS2-Powered C6 Corvette In Italian Clothes
Verdad Gallardo
Awesome K5 Blazer Restomod Comes With C7 Corvette Power
Verdad Gallardo
10 Camaros You Should Never Buy
10 LS Engine Myths That Refuse to Die
Verdad Gallardo
That cam has a ton of overlap for a TT street setup stick car. You'd pick up spool and boost with a smaller cam that'll drive better. Id care less about which of those turbos to pick and more about your cam.
Where are you finding H/C swaps that approach 600whp (and are street drive-able)? Short term(1-2 year) goal is the 600-650whp, but I'm not going to pretend that I won't turn it up at some point. I'm just trying to take it in steps so I don't destroy the car or myself right away.
I decided on twins for quicker spool. I was already removing ABS, AC & PS, so space wasn't a concern.
I decided on twins for quicker spool. I was already removing ABS, AC & PS, so space wasn't a concern.
If all you want is 600-800hp a 76mm will be like a lightswitch on an 11:1 370. You can cam twins more like an NA car, but for a single I would back the cam down a bit.
