Just taking an extended break from the madness again so been surfing here! I didn't realize the racing season started so late there. I am dying to hear how you make out. I think you will be impressed how far you can push that little LM7!
April was cold and had a lot of rain, so GLD ever opened it's opening tomorrow but there is rain in the forecast. Usually the track is sh%% first week and crowded pointless do anything..
I’ve had 0 issues with LS9 gaskets on the alum 5.3.
However, I’m switching to the BTR “small bore” version with my new LC9 block.
You should check them out.
Currently my '67 is running a LM7 SBE, stock L99 heads, a Capizzi cam grind, ARP hardware and a Melling oil pump. My long term plan has been to build a forged LC9 and to run aftermarket heads.
I've been working with the following industry players for an all-forged boost engine that is getting built this year:
Here is the list of parts that will be used. I'm still updating and adding to the list, so it's not complete yet:
GM LC9 engine block, bored .005 over
TFS-30619991 TFS 220 Cylinder Heads
SUM-180LS362224x Pro LS 3.622 crank
SUM-LS6125927 Pro LS 6.125 H-Beam rods with ARP 2000’s
SUM-2999273785-7 Pistons
ARP-234-4317 Head studs
ARP-234-5608 Main Studs
AAF-ALL87024 Cylinder head dowels
NAL-12575329 Chevy Performance O.E. 5.3L bore replacement head gaskets
TFS-21407500 pushrods
SUM-HTLSKIT2 Delphi LS7 lifter and tray kit
NAL-12561513 Long Crank Key
SUM-161000 Short Crank Key
CLE-SH2125S Cam Bearings
MEL-10295 Melling Oil pump
SUM-G1585 LS Engine Hardware Kit / Plugs Dumbbell/ Side Bolts
SUM-G2627 Cam Change Gasket kt
SUM-G2621 Rear Cover with Main Seal
SUM-150106 Cam Retainer Plate
ARP-134-1003 Cam Bolts
ARP 234-2503 Crank Bolt
TFS-30675540 Timing Chain damper
ARP-200-8683 Windage Tray Nuts
ARP-671-1002 Oil pump Bolts
ICB-551432 Timing Cover bolts
SUM ___ LS engine diaper
I plan to reuse my Holley 302-2 oil pan and Holley High Ram intake.
The block is over with Graham Jones @ FastTimes. He determined that we are good with a .005 over bore which was going to effect the piston selection.
I kicked back and forth staying stock crank but the one in the builder block was not usable so that was not even an option.
Again this is a parts list in progress, I'll note when it's been edited.
Good choice on the 10295 pump. Always have great luck with those and the right bearing clearances for the application.
Interesting choice on the Delphi LS7 lifters. I do like the GM LS7 lifters for moderate, to budget builds. What are the spring pressures you are having Graham target?
Tim (Helicoil), LS7 lifters are more budget friendly but I know a lot of really knowledgeable folks including yourself would favor something like a Johnson 2110. I need to do a little more thinking about it.
I have had good luck with the GM Ls7 lifters and the right spring pressures, I was just noting the Delphi versions, may not be the good ole' GM lifters. Be cautious.
