Thread chaser for head bolt threads
#1
Thread chaser for head bolt threads
Well I've recently discovered that GM used a 11mm x 2.0 thread in the block for the head bolts. I was wanting to chase the threads in the block before I install the heads. Does anyone have an alternative to the $60 thread chaser from ARP that I will only use this one time? I do not have any of the old head bolts to make into a thread chaser.
#2
12 Second Club
Join Date: Apr 2013
Location: Bourg La
Posts: 232
Likes: 0
Received 0 Likes
on
0 Posts
Well I've recently discovered that GM used a 11mm x 2.0 thread in the block for the head bolts. I was wanting to chase the threads in the block before I install the heads. Does anyone have an alternative to the $60 thread chaser from ARP that I will only use this one time? I do not have any of the old head bolts to make into a thread chaser.
#4
The following users liked this post:
grubinski (12-12-2020)
Trending Topics
The following 2 users liked this post by LilJayV10:
00pooterSS (12-14-2020), WE TODD DID (12-15-2020)
#12
TECH Enthusiast
Just get an inexpensive tap and die set and use the appropriate sized tap to chase the threads. Then you also have a tap and die set you can use again and again in the future.
The following 3 users liked this post by Rich-L79:
#13
Launching!
iTrader: (1)
For all the people suggesting using a tap - NO. You NEVER want to run a tap down into a head bolt hole because it will remove too much material and make the thread weaker. If this is an alloy block, kiss that hole goodbye. You need to use a chaser or cut a slot into a factory bolt. These methods remove minimal material and mainly just form the thread back into place. An actual form tap would be ideal for this but M11 is a non-standard thread so I doubt you’ll find one for cheaper than ARP’s chaser.
The following 2 users liked this post by Sacrilege:
Kfxguy (12-17-2020), Old Geezer (12-14-2020)
The following users liked this post:
WE TODD DID (12-15-2020)
#16
TECH Enthusiast
For all the people suggesting using a tap - NO. You NEVER want to run a tap down into a head bolt hole because it will remove too much material and make the thread weaker. If this is an alloy block, kiss that hole goodbye. You need to use a chaser or cut a slot into a factory bolt. These methods remove minimal material and mainly just form the thread back into place. An actual form tap would be ideal for this but M11 is a non-standard thread so I doubt you’ll find one for cheaper than ARP’s chaser.
The following users liked this post:
CattleAc (12-14-2020)
#17
TECH Veteran
iTrader: (40)
Good luck finding a tap/chaser long enough
That's part of why everyone recommends, and uses, an old head bolt or the ARP tool.
The old head bolt is free, the right length, wont harm the threads etc etc
That's the only answers, it's been explained many times, and people are still asking
That's part of why everyone recommends, and uses, an old head bolt or the ARP tool.
The old head bolt is free, the right length, wont harm the threads etc etc
That's the only answers, it's been explained many times, and people are still asking
The following users liked this post:
WE TODD DID (12-15-2020)
#19
TECH Fanatic
iTrader: (7)
Well I've recently discovered that GM used a 11mm x 2.0 thread in the block for the head bolts. I was wanting to chase the threads in the block before I install the heads. Does anyone have an alternative to the $60 thread chaser from ARP that I will only use this one time?
You can always resell the good one when your done with it. recoup some of your initial investment...
