Default Door speakers replacement (monsoon)

I am having a terrible time trying to find something that mounts and wires the same as the stock Monsoon 6.5 and tweeter.

They are mounted co-axially and appear to be a 2-way speaker, but are actually wired as separate components

Some places on the interwebs refer to this arrangement as a 'braxial' speaker system. Another way I have seen this described is as a 'convertible component' speaker system.

Any brand or specific model recommendations? Where/how should I shop/search for this?
Old 11-06-2013 | 08:20 AM
  #2
wssix99's Avatar
Save the manuals!
15 Year Member
iTrader: (5)

Joined: Dec 2007
Posts: 12,774
Likes: 358
From: Chicago, IL
Default

Start in the stickes of this section. You'll find lots of good information to start, there.
Old 11-06-2013 | 11:02 AM
  #3
hooker2007's Avatar
Thread Starter
On The Tree

Joined: Nov 2013
Posts: 118
Likes: 5
Default

Originally Posted by wssix99
Start in the stickes of this section. You'll find lots of good information to start, there.
I have read the FAQ and sticky a few times... no mention of speaker replacement options outside of what the sponsors have packaged. And frankly, the sponsors are asking way too much for some no-name brand.
The following users liked this post:
Y2K_Frenzy (06-07-2024)
Old 11-06-2013 | 01:29 PM
  #4
Blownbayou's Avatar
TECH Enthusiast

iTrader: (7)

Joined: Dec 2008
Posts: 653
Likes: 6
From: South Louisiana
Default





Picture for you

Cut the tweeter leads from the main post and voila'....... Two sets of leads for the monsoon radio. The tweeter will be louder, so make sure you set it on -3 located on the front. I did anyways
Old 11-06-2013 | 02:02 PM
  #5
hooker2007's Avatar
Thread Starter
On The Tree

Joined: Nov 2013
Posts: 118
Likes: 5
Default

Wow! That makes it seem like any 2-way 6.5 could be modified the same way as long as you had easy access to the tweeter leads....

I wonder if its really that simple, or if it has to be a specific brand.
Old 11-06-2013 | 02:25 PM
  #6
Blownbayou's Avatar
TECH Enthusiast

iTrader: (7)

Joined: Dec 2008
Posts: 653
Likes: 6
From: South Louisiana
Default

as long as you have easy access.... should work for any brand
Old 11-06-2013 | 02:38 PM
  #7
2002ss335's Avatar
On The Tree

Joined: Jan 2012
Posts: 183
Likes: 0
From: Ohio
Default

Check out Kee Audio, I bought his Premium Package a couple of years ago or you can just buy the door speakers.

http://www.keeaudio.com/fbodyspeakers.html
Old 11-06-2013 | 02:43 PM
  #8
M4N14C's Avatar
TECH Fanatic
iTrader: (3)

Joined: Apr 2013
Posts: 1,233
Likes: 16
From: Redmond, WA
Default

Originally Posted by 2002ss335
Check out Kee Audio, I bought his Premium Package a couple of years ago or you can just buy the door speakers.

http://www.keeaudio.com/fbodyspeakers.html
+1 on Kee Audio. Got their level 3 package and I'm very satisfied.
Old 11-06-2013 | 02:53 PM
  #9
Majestic9C1's Avatar
TECH Fanatic
iTrader: (19)

Joined: Jun 2013
Posts: 1,655
Likes: 22
From: Cincinnati, OH
Default

JBL GTO628's are 2 ohm and should work... I plan on getting some soon..
I already replaced the hatch speakers with some Kenwood 4 inch 3 ways.. sounds much better..
Old 11-06-2013 | 02:54 PM
  #10
autogeek23's Avatar
TECH Enthusiast
10 Year Member
iTrader: (13)

Joined: Apr 2011
Posts: 682
Likes: 14
From: Parma Heights,Ohio
Default

I want the level 3 from kee audio! hear nothing but good things
Old 11-07-2013 | 06:53 AM
  #11
wssix99's Avatar
Save the manuals!
15 Year Member
iTrader: (5)

Joined: Dec 2007
Posts: 12,774
Likes: 358
From: Chicago, IL
Default

Originally Posted by hooker2007
I have read the FAQ and sticky a few times... no mention of speaker replacement options outside of what the sponsors have packaged. And frankly, the sponsors are asking way too much for some no-name brand.
When you buy a name brand speaker, a large portion of what you pay goes to the company's marketing campaigns, pictures of chicks on Italian cars, etc. Not necessarily a quality product.

You should do a little more research in to these brands you aren't aware of. Speakers are one product where you can find higher quality from smaller local companies. Many of the brand names you are familiar sell cheap paper speakers made in Chinese labor camps, etc. where many of the companies that don't heavily market to you make a higher quality product made in the USA or the west.

There are lots of threads on this site talking about the quality/build of the speakers that the sponsors are putting in their packages.
Old 11-11-2013 | 12:06 PM
  #12
OhTwo's Avatar
Launching!
20 Year Member
iTrader: (13)

Joined: Jul 2003
Posts: 253
Likes: 16
From: Urbandale, IA
Default

One more vote for Kee Audio. I've had my car since it was new and lost both sail panel speakers in my TA. Replaced the entire setup with a high end option from Kee and it's great. There are numerous other options and some certainly more expensive. I needed something so I could hear over my loud exhaust and sound decent without costing a small fortune.
Old 11-11-2013 | 08:11 PM
  #13
SweeTbone's Avatar
11 Second Club
iTrader: (8)

Joined: Feb 2005
Posts: 2,545
Likes: 7
From: Toledo, OH
Default

Another vote for Kee Audio. Got the level 2 package in my Bird with all the CDT stuff and it sounds great for sure.
Old 11-19-2013 | 04:11 PM
  #14
polorico's Avatar
Staging Lane

Joined: Sep 2013
Posts: 87
Likes: 0
Default

Yeah i am in the process of building a quality sound system.

I am looking at the Kee audio packages. I have never heard of these brands.

I think i might go with alpine..

Is it a necessity to go with the subs ? i was going to just do 2 front door speakers with tweeters (componet system) and two rear door speakers... or do i need to replace the subs and the rear hatch ? i wont be using an amp right away to power the system . but i will have a alpine head unit.
Old 11-19-2013 | 04:51 PM
  #15
blade2222's Avatar
TECH Apprentice

Joined: Jul 2007
Posts: 364
Likes: 0
Default

The sail panel speakers put out most of the bass. Mine went out and like a dumb *** I replaced them with some two way speakers and it sounded like crap. Then I came here and read up on it and replaced them with some mid range subs and all is good again.
Old 11-19-2013 | 07:28 PM
  #16
polorico's Avatar
Staging Lane

Joined: Sep 2013
Posts: 87
Likes: 0
Default

^ do you have an amp powering them ?

i prolly wont have an amp attached to my set up initially.
Old 11-20-2013 | 10:09 AM
  #17
wssix99's Avatar
Save the manuals!
15 Year Member
iTrader: (5)

Joined: Dec 2007
Posts: 12,774
Likes: 358
From: Chicago, IL
Default

Originally Posted by polorico
I am looking at the Kee audio packages. I have never heard of these brands.

I think i might go with alpine..
That would be a good choice, because I think Alpine gives you a free car with every purchase:



You won't find a lot of mass-marketed brands that have equipment that is a direct-fit for an F-Body or compatible with he existing components. So, if you go with one of those brands, you may have to do some innovative fabrication (like the OP did here) or replace the entire system all in one step.

Likewise, you will likely find many unfamiliar brands with higher quality than mass-produced/imported equipment.

Last edited by wssix99; 11-20-2013 at 10:15 AM.
Old 11-20-2013 | 11:18 AM
  #18
WhiteBird00's Avatar
Ungrounded Moderator
20 Year Member
iTrader: (4)

Joined: Nov 2003
Posts: 11,153
Likes: 291
From: Jacksonville, FL
Default

Originally Posted by polorico
^ do you have an amp powering them ?

i prolly wont have an amp attached to my set up initially.
If you don't plan to add an aftermarket amp, why don't you keep the existing Monsoon amp? It's not particularly powerful but it's certainly more power than head unit alone. And keeping the amp makes the wiring a simple matter of an adapter harness for your head unit.
Old 12-02-2013 | 02:46 PM
  #19
KEE AUDIO's Avatar
Banned
iTrader: (65)

Joined: Sep 2004
Posts: 2,851
Likes: 2
From: Marietta, GA
Default

Originally Posted by hooker2007
I have read the FAQ and sticky a few times... no mention of speaker replacement options outside of what the sponsors have packaged. And frankly, the sponsors are asking way too much for some no-name brand.
Nice, brand new to the forums and on your 3rd post are already criticizing the sponsors here. Never ceases to amaze me...

It's fine to be ignorant about speaker companies and who makes high end gear beyond what Best Buys and Walmart have, but do a little research before you decide to post BS like that, criticizing guys like me who have been on here for 9 years helping people with car audio stuff.
Old 12-03-2013 | 12:14 PM
  #20
WhiteBird00's Avatar
Ungrounded Moderator
20 Year Member
iTrader: (4)

Joined: Nov 2003
Posts: 11,153
Likes: 291
From: Jacksonville, FL
Default

While I agree with you Ian, you're tilting at windmills because the newbie hasn't been back here since early November. I doubt he'll see your comment.
