A little lower end install on 99 C-5 Vette (wholly **** Phil!), little of everything DynoTune, NX, Nitrous Outlet and HSW.
NX Bottle (no opener), NX -4 wingnut on a -4 DynoTune dual gaugeport swivel, with a DynoTune Remote Pressure Gauge to the mainline and a NX Nitrous Filter. Bottle covered by a Dynotune Blanket I had the local embroidery gals put the C-5 Logo to it. Dynotune billet bottle bracket.
Street Bottle w/ DynoTune opener
Home grown Panel
NX Dry Nozzles
Nitrous Outlet (Nitro Dave) LS1 Wet Plate, Double NX Stage Six Lightning Noids,w/ Custom HSW hoses and Y, hardlined and final system wiring by Vin @ 860 Performance
Autometer gauge pod with DynoTune Gauges.
NX Bottle (no opener), NX -4 wingnut on a -4 DynoTune dual gaugeport swivel, with a DynoTune Remote Pressure Gauge to the mainline and a NX Nitrous Filter. Bottle covered by a Dynotune Blanket I had the local embroidery gals put the C-5 Logo to it. Dynotune billet bottle bracket.
Street Bottle w/ DynoTune opener
Home grown Panel
NX Dry Nozzles
Nitrous Outlet (Nitro Dave) LS1 Wet Plate, Double NX Stage Six Lightning Noids,w/ Custom HSW hoses and Y, hardlined and final system wiring by Vin @ 860 Performance
Autometer gauge pod with DynoTune Gauges.
Last edited by Beer99C5; Aug 17, 2006 at 01:25 AM.
Originally Posted by ivandrea
Here's what I have so far.
The purge shoots out from the center of the hood where the heat extractor is. You can see the line I have routed next to the TB, near the transition tube.
The purge shoots out from the center of the hood where the heat extractor is. You can see the line I have routed next to the TB, near the transition tube.
