Stand-Alone Trans Cooler
B&m 70274. This is only cooler I’ve used on a few vehicles now and it does a really good job. Don’t have experience with other ones. Always used as a stand-alone, personally just don’t like going thru the radiator.
on the f car, have it mounted directly behind where the ta front bumper plate cover is I have one of those mesh bird plate covers so it gets plenty of airflow.
on the f car, have it mounted directly behind where the ta front bumper plate cover is I have one of those mesh bird plate covers so it gets plenty of airflow.
Moderator
Joined: Aug 2010
Posts: 7,323
Likes: 529
From: Ann Arbor, MI
Can cayenne just create a new post. Then that picture. Then we can have 4 or 5 guys post pictures of different common locations for f body cooler placement.
Then sticky it
then close it
@mrvedit
Then sticky it
then close it
@mrvedit
TECH Junkie
Joined: Dec 2012
Posts: 3,614
Likes: 1,326
From: Iowa
Trending Topics
TECH Junkie
Joined: Nov 2013
Posts: 3,913
Likes: 366
From: White Bear, Mn
@98CayenneT/A it's your time. hahaha
I will create a new post @mrvedit feel free to edit my title whatever I end up calling it.
If I had $100 for every time I posted that picture.... not to mention all the times I could have but didn't feel like it..... Google my friends goes a long ways.
Searching stand alone transmission cooler followed by simply putting Ls1 after would yield more results than one would have time to go through.
LS1 Tech Stories
The Best V8 Stories One Small Block at Time
6 Common C5 Corvette Failures and What's Involved In Repairing Them
Pouria Savadkouei
Retro Modern Bandit Pontiac Trans AM Comes With Burt Reynolds' Autograph
Verdad Gallardo
Top 10 Greatest Cadillac V Series Performance Models Ever, Ranked
Pouria Savadkouei
Top 10 Most Powerful Chevy Trucks Ever Made!
Hennessey's New Supercharged Silverado ZR2 Has 700 HP
Verdad Gallardo
Coachbuilt N2A Anteros Is an LS2-Powered C6 Corvette In Italian Clothes
Verdad Gallardo
Awesome K5 Blazer Restomod Comes With C7 Corvette Power
Verdad Gallardo
10 Camaros You Should Never Buy
10 LS Engine Myths That Refuse to Die
Verdad Gallardo Moderator
Joined: Aug 2010
Posts: 7,323
Likes: 529
From: Ann Arbor, MI
98Cayenne's post is now a sticky. Hopefully people won't abuse that thread.
It mentions that general discussion about external coolers can continue here.
Here are some older threads on the subject (please don't post on old threads; post questions and discussion here.)
https://ls1tech.com/forums/forced-in...s-coolers.html
https://ls1tech.com/forums/ls4-perfo...must-read.html
https://ls1tech.com/forums/ls4-perfo...r-install.html
It mentions that general discussion about external coolers can continue here.
Here are some older threads on the subject (please don't post on old threads; post questions and discussion here.)
https://ls1tech.com/forums/forced-in...s-coolers.html
https://ls1tech.com/forums/ls4-perfo...must-read.html
https://ls1tech.com/forums/ls4-perfo...r-install.html
Has anyone used a Tru cool 40K? I got my banjo fittings for my 4L80E and plan to run custom length hose to that. I have a Hayden 679 which works great on a 4L60E handling 450 hp, but will it be enough for a 4L80E handling 1200?
I had a 70264 running "dope style" and that configuration resulted in temps that were higher than my liking, so I didn't even bother trying it mounted normally, I just jumped to the Hayden 679 and it's been working great.
I had a 70264 running "dope style" and that configuration resulted in temps that were higher than my liking, so I didn't even bother trying it mounted normally, I just jumped to the Hayden 679 and it's been working great.
TECH Junkie
Joined: Jun 2008
Posts: 3,202
Likes: 1,390
From: Nitro Alley
Nothing beats water cooling... well at least compared to air cooling.
Air-Con. refrigerant based cooling also works damn well!!!
ATF/ oil coolers that work with or in the engine cooling system radiator are ideal... using an air cooler (like a True-cool) in conjunction works very well.
I have used two (in series) of the Long/ True cool 11"x 11" or 12"x 12" oil coolers in front of a heavy-duty radiator and heavy-duty electric fans combo in high powered vehicles...
No water to ATF cooling unfortunately on this particular build... but with great air-flow, custom fan-shrouding, ducting, air-dam, and design... it worked great!!!
O!!! and a Thermostatic valve should be used to keep the ATF bypassing the coolers, less the fluid is up to temperature.
There is no real harm keeping the transmission cooler than operating temperature...
But from a performance stand-point and an ATF longevity point... it is ideal to have the temp in the 160*F to 180*F range.
Air-Con. refrigerant based cooling also works damn well!!!
ATF/ oil coolers that work with or in the engine cooling system radiator are ideal... using an air cooler (like a True-cool) in conjunction works very well.
I have used two (in series) of the Long/ True cool 11"x 11" or 12"x 12" oil coolers in front of a heavy-duty radiator and heavy-duty electric fans combo in high powered vehicles...
No water to ATF cooling unfortunately on this particular build... but with great air-flow, custom fan-shrouding, ducting, air-dam, and design... it worked great!!!
O!!! and a Thermostatic valve should be used to keep the ATF bypassing the coolers, less the fluid is up to temperature.
There is no real harm keeping the transmission cooler than operating temperature...
But from a performance stand-point and an ATF longevity point... it is ideal to have the temp in the 160*F to 180*F range.
